Modular Floodlight 400W, 6500K

Modular LED floodlight for large outdoor areas.

CodeLUZ-F7400-65

Spec sheet PDF

Light colour 6500K

Power400 W 100-240V AC

Light output48000 lm 120 lm/W

Beam angle 60 to 120°

Protection IP65 Outdoor use, rain and dust proof.

Colour rendering Ra 70 For outdoor and industrial areas.

Specifications

Light

Luminous flux: 48000 lm
Efficacy: 120 lm/W
Colour temperature: 6500K
Colour rendering: Ra 70
Beam: 120 x 60 degrees
Lifetime: >54000 h (L70 at 30 °C)

Electrical

Power: 400 W
Input: 100-240V AC
Driver: Constant current, isolated
Power factor: ≥0.95
Protection class: I
Surge protection: 5 kV

Build and installation

Size: 565 x 545 x 65 mm
Weight: 9.4 kg
Material: Aluminium alloy housing, PC lens
IP rating: IP65
IK rating: IK10
Ambient temperature: -40 to 50 °C
Cable: 0.2 to 0.3 m

About this product

It fixes to a mast, a wall or a structure by its bracket and is wired to the mains through its short power lead. The bracket tilts to aim the light, and the LED modules behind their lenses spread a wide, even field of cool white light from one mounting point.
